Boeing C-17 Globemaster III - Emergency manual gear extension
by Cavok · · Pápa, Hungary · day · 2492 views
In the event of a failure of the aircraft's landing gear extension mechanism a backup is provided. This may be an alternate hydraulic system, a hand-crank, compressed air (nitrogen), pyrotechnic or free-fall system.
A free-fall or gravity drop system uses gravity to deploy the landing gear into the down and locked position. To accomplish this the pilot activates a switch or mechanical handle in the cockpit, which releases the up-lock. Gravity then pulls the landing gear down and deploys it. Once in position the landing gear is mechanically locked and safe to use for landing. (Wikipedia)
A free-fall or gravity drop system uses gravity to deploy the landing gear into the down and locked position. To accomplish this the pilot activates a switch or mechanical handle in the cockpit, which releases the up-lock. Gravity then pulls the landing gear down and deploys it. Once in position the landing gear is mechanically locked and safe to use for landing. (Wikipedia)
Labels on this photo
- Boeing C-17 Globemaster III Make: (e.g. Boeing): Boeing · Model: (e.g. 737): C-17 Globemaster III · Type: (e.g. jetliner): jetliner · Operator/Airline:: Hungarian Air Force · Registration (e.g. EI-DWR): 08-0002 · Serial number:: F-210/SAC-2
